LMW-12W-50K
LED Mini Cutoff Wall Packs
Technical Specs
- :: Die-Cast Aluminium with Powder Coat Finish
- :: High Transparent Tempered Glass
- :: Lumens: 1300LM
- :: Wattage: 12W
- :: Voltage: 120-277VAC 80Hz
- :: Chip: Lumileds Lexeon 3030 High Flux LED
- :: Efficacy: 125/130/135 LPW
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 100° x 100°
- :: Power Factor: >0.9
- :: Operating Temp: -40°F to 104°F
- :: Lifespan: 70,000 hours
- :: 7-year warranty
- :: IP Rating: IP54, Wet Locations
Applications
- :: Ideal for general site lighting, alleys, loading docks, pathways, parking areas, residential areas, balcony, terrace and small shops.
Features
ACCESSORIES
| Product Name | Dimensions | Description | |||
|---|---|---|---|---|---|
 WMS-POST1-18  CAT SPEC MANU | 18"(H) x 5""(L) x 2.3""(W)" | 18" One side post for WMS series" | |||
WMS-POST2-36 CAT SPEC MANU | 36"(H) x 5""(L) x 2.3""(W)" | 36" Two side post for WMS series" | |||
WMS-POST2-18 CAT SPEC MANU | 18"(H) x 5""(L) x 2.3""(W)" | 18" Two side post for WMS series" | |||
WMS-POST1-36 CAT SPEC MANU | 36"(H) x 5""(L) x 2.3""(W)" | 36" One side post for WMS series" |
OPTIONS
