LFX-SERIES

LFX - LED Power-Adjustable Flood/Area Light

Technical Specs

:: Voltage: 120~277V AC/50~60 Hz
:: Wattage: 50W-600W
:: Power Factor: >0.9
:: Efficacy: 135LPW-140LPW
:: With Snap-on & Bolt Mounting Options for One-Person Installations. Select a Mounting Option (Sold Separately)
:: LED: Lumileds Luxeon 2835 High Flux LED
:: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
:: IP Rating: IP65
:: 10KV Lightning Surge Protection
:: Aluminum LED Board: High Conductive, Waterproof, Aging Resistance, Salt Mist Resistance, Ensure the Safety, and Long Lifespan
:: Operating Temperature: -104°F to 122°F
:: Effective Projected Areas (EPA's) are: Front = 0.38 Square Feet, Side = 0.30 Square Feet, Face 1.05 Square Feet
:: Suitable for Wet Locations
:: Dimming: 0~10V Dimmable
:: Optical Lens: High Light Transmitance PC, Anti-UV, and Flame Resistant
:: Lens: Type III°
:: Total Lumens: 21400LM-84000LM Max.
:: Color Temperature: 3000K/4000K/5000K
:: Color Rendering Index: ≥ 82
:: Beam Angle: 120°X 90°

Applications

:: Ideal for general site lighting, alleys, loading docks, doorway, pathway, and parking areas.
:: Replace existing HID flood lights/ wall packs.

Variations
Q & A (2)

Product Name	Lumens	Color Temp	Watts	Dimensions	Description	Factory-Installed Options
LFX-LG-50-150W-30K SPEC SPD INST	21400LM Max.	3000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		OPT-LF3-PCK OPT-SEN-3MR-3 OPT-3MPC WEC-8RC OPT-TLSOC7P OPT-EM-LFX-LG
LFX-LG-50-150W-40K SPD INST SPEC	21400LM Max.	4000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		OPT-LF3-PCK OPT-SEN-3MR-3 OPT-3MPC WEC-8RC OPT-TLSOC7P OPT-EM-LFX-LG
LFX-LG-50-150W-50K SPEC SPD INST	21400LM Max	5000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		OPT-LF3-PCK OPT-SEN-3MR-3 OPT-3MPC WEC-8RC OPT-TLSOC7P OPT-EM-LFX-LG
LFX-XL-150-300W-30K SPEC SPD INST	44000LM Max.	3000K	150W/200W/240W/300W	19 5/8”(H) x 12-5/8”(W) x 3-3/4”(D)		OPT-LF3-PCK OPT-SEN-3MR-3 OPT-3MPC WEC-8RC OPT-TLSOC7P OPT-EM-LFX-XL
LFX-XL-150-300W-40K SPEC SPD INST	44000LM Max.	4000K	150W/200W/240W/300W	19 5/8”(H) x 12-5/8”(W) x 3-3/4”(D)		OPT-LF3-PCK OPT-SEN-3MR-3 OPT-3MPC WEC-8RC OPT-TLSOC7P OPT-EM-LFX-XL
LFX-XL-150-300W-50K SPEC SPD INST	44000LM Max.	5000K	150W/200W/240W/300W	19-5/8"H x 12-5/8"W x 3-3/4"D		OPT-LF3-PCK OPT-SEN-3MR-3 OPT-3MPC WEC-8RC OPT-TLSOC7P OPT-EM-LFX-XL
LFX-XXL-300-600W-50K SPEC INST SPD	84000LM Max.	5000K	300W/400W/500W/600W	25-5/8"H x 12-3/4"W x 3-3/8"D		OPT-LF3-PCK OPT-SEN-3MR-3 OPT-3MPC WEC-8RC OPT-TLSOC7P OPT-EM-LFX-XXL
LFX-XXL-300-600W-50K-480V SPEC INST SPD	84000LM Max.	5000K	300W/400W/500W/600W	25-5/8"H x 12-3/4"W x 3-3/8"D		OPT-LF3-PCK-480V OPT-SEN-3MR-3 WEC-8RC OPT-EM-LFX-XXL
WEC-8RC SPEC					Remote Control For WEC-3MR-4 & WEC-3MR-3
LFX-ASA SPEC BRCH					Adjustable Straight Arm, 8-1/8"L x 3-1/2"W x 5-3/4"H
LFX-YK SPEC BRCH					Yoke, 6"L x 2"W x 5-3/4"D
LFX-EXT SPEC BRCH					Straight Arm, 3-1/3"W x 6-3/4"L x 4-3/8"H
LFX-TR-A BRCH					U Bracket, 13-3/8"L x 10-1/8"W
LFX-SF BRCH SPEC					Slip Fitter, 3-1/3"W x 9-7/8"L
LFX-TR-B BRCH					U Bracket, 13-1/2"L x 12"W
LFX-PASF BRCH SPEC					Pole Adapter for LFX-SF Slip Fitter, 6-1/8"H x 3-1/4"W x 3"D
LFX-AWB SPEC					Adjustable Wall Junction Box, 6-5/8"L x 5-3/4"W x 7-1/8"D
LF-SHROUD-A SPEC					Shroud, 10-5/8"L x 6-1/8"W x 4-3/4"D
LF-SHROUD-B SPEC					Shroud, 12-5/8"L x 10-5/8"W x 5-1/2"D
LF-SHROUD-D SPEC					Full-Glare Shroud, 10-5/8"L x 6-1/4"W x 4-3/4"D
LF-SHROUD-E SPEC					Full-Glare Shroud, 12-3/4"L x 10-5/8"W x 5-1/2"D
LF-SHROUD-F SPEC					Shroud, 12-3/4"L x 10-5/8"W x 5-1/2"D
LF-SHROUD-G SPEC					Full-Glare Shroud, 12-3/4"L x 10-5/8"W x 5-1/2"D
LFX-WG-A SPEC					Wire Guard
LFX-WG-B SPEC					Wire Guard
LFX-LG-50-150W-30K-480V SPEC INST SPD	21400LM Max.	3000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		WEC-8RC OPT-LF3-PCK-480V OPT-EM-LFX-LG OPT-3MPC
LFX-LG-50-150W-40K-480V SPEC INST SPD	21400LM Max.	4000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		WEC-8RC OPT-LF3-PCK-480V OPT-3MPC OPT-EM-LFX-LG
LFX-LG-50-150W-50K-480V SPEC SPD INST	21400LM Max.	5000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		WEC-8RC OPT-LF3-PCK-480V OPT-3MPC OPT-EM-LFX-LG
LFX-LG-80-150W-MCTP-480V-SC SPEC SPD INST	21750LM Max.	3000K/4000K/5000K	80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		WEC-8RC OPT-EM-LFX-LG
LFX-XL-200-300W-MCTP-480V-SC SPEC INST SPD	43500LM Max.	3000K/4000K/5000K	200W/240W/300W	19 5/8”(H) x 12-5/8”(W) x 3-3/4”(D)		WEC-8RC OPT-EM-LFX-XL
LFX-XL-150-300W-50K-480V SPEC SPD INST	44000LM Max.	5000K	150W/200W/240W/300W	19-5/8"H x 12-5/8"W x 3-3/4"D		WEC-8RC OPT-EM-LFX-XL OPT-LF3-PCK-480V OPT-3MPC
LFX-LG-50-150W-30K-SC SPD INST SPEC	21000LM Max.	3000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-LG
LFX-LG-50-150W-40K-SC SPEC SPD INST	21000LM Max.	4000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-LG
LFX-LG-50-150W-50K-SC SPEC SPD INST IES BRCH	21000LM Max.	4000K	50W/80W/100W/150W	11”(H) x 12-5/8”(W) x 3-3/8”(D)		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-LG
LFX-XL-150-300W-30K-SC SPEC SPD INST	43500LM Max.	3000K	150W/200W/240W/300W	19 5/8”(H) x 12-5/8”(W) x 3-3/4”(D)		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-XL
LFX-XL-150-300W-40K-SC SPEC SPD INST	43500LM Max.	4000K	150W/200W/240W/300W	19 5/8”(H) x 12-5/8”(W) x 3-3/4”(D)		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-XL
LFX-XL-150-300W-50K-SC SPEC SPD INST BRCH IES	44000LM Max.	5000K	150W/200W/240W/300W	19-5/8"H x 12-5/8"W x 3-3/4"D		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-XL
LFX-XXL-300-600W-50K-SC SPEC INST SPD	84000LM Max.	5000K	300W/400W/500W/600W	25-5/8"H x 12-3/4"W x 3-3/8"D		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-XXL
LFX-XXL-300-600W-50K-480V-SC SPEC SPD INST	84000LM Max.	5000K	300W/400W/500W/600W	19 5/8”(H) x 12-5/8”(W) x 3-3/4”(D)		WEC-8RC OPT-SEN-3MR-3 OPT-EM-LFX-XXL

ACCESSORIES

Product Name	Description
LFX-ASA SPEC BRCH	Adjustable Straight Arm, 8-1/8"L x 3-1/2"W x 5-3/4"H
LFX-YK SPEC BRCH	Yoke, 6"L x 2"W x 5-3/4"D
LFX-EXT SPEC BRCH	Straight Arm, 3-1/3"W x 6-3/4"L x 4-3/8"H
LFX-TR-A BRCH	U Bracket, 13-3/8"L x 10-1/8"W
LFX-SF BRCH SPEC	Slip Fitter, 3-1/3"W x 9-7/8"L
LFX-TR-B BRCH	U Bracket, 13-1/2"L x 12"W
LFX-PASF BRCH SPEC	Pole Adapter for LFX-SF Slip Fitter, 6-1/8"H x 3-1/4"W x 3"D
LFX-AWB SPEC	Adjustable Wall Junction Box, 6-5/8"L x 5-3/4"W x 7-1/8"D
LF-SHROUD-A SPEC	Shroud, 10-5/8"L x 6-1/8"W x 4-3/4"D
LF-SHROUD-B SPEC	Shroud, 12-5/8"L x 10-5/8"W x 5-1/2"D
LF-SHROUD-D SPEC	Full-Glare Shroud, 10-5/8"L x 6-1/4"W x 4-3/4"D
LF-SHROUD-E SPEC	Full-Glare Shroud, 12-3/4"L x 10-5/8"W x 5-1/2"D
LF-SHROUD-F SPEC	Shroud, 12-3/4"L x 10-5/8"W x 5-1/2"D
LF-SHROUD-G SPEC	Full-Glare Shroud, 12-3/4"L x 10-5/8"W x 5-1/2"D
LFX-WG-A SPEC	Wire Guard
LFX-WG-B SPEC	Wire Guard

OPTIONS

OPT-LF3-PCK

OPT-SEN-3MR-3

OPT-3MPC
