SCX-8FT-80W-50K-D

LED 2-3/4" Superior Architectural Seamless Linear Lights

Technical Specs

  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 8800LM
  • :: Color Temperatures: 5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life

Applications

  • :: Ideal for offices, hotels, corridors, saloons, libraries,meeting rooms, conference halls, and the bestsolution for modern lighting solutions.
  • :: It can be used in any indoor applications.

Features

    Q & A

    No questions posted yet for this product!

    ACCESSORIES

    Product NameDescriptionDimensionsLumensColor Temp
    image description
    		ADJ. 6FT 1/16in, 1.5mm SINGLE SUSPENSION 5in CANOPY SET WITH KEYHOLE END CONNECTOR, NONPOWER SIDE
    image description
    		White 6ft. Cord, SJTW 18 AWG 6-Conduct (WH/BK/GN/PU/GY + Red for Emergency)
    image description
    		ADJ. 6FT 1/16in, 1.5mm SINGLE SUSPENSION 5in CANOPY SET WITH KEYHOLE END CONNECTOR, POWER SIDE WITH SJTW18/5 WHITE CORD
    image description
    		ADJ. 6FT 1/16in,1.5mm SINGLE SUSPENSION 5in CANOPY SET WITH KEYHOLE END CONNECTOR, POWER SIDE WITHOUT CORD
    image description
    		1/16" 500 FT. steel aircraft suspension cable
    image description
    		Joint Type: L5.75” X 5.75”X 3.35” X 2.75”508LM3000K
    image description
    		Joint Type: L5.75” X 5.75”X 3.35” X 2.75”575LM3500K
    image description
    		Joint Type: L5.75” X 5.75”X 3.35” X 2.75”616LM4000K
    image description
    		Joint Type: L5.75” X 5.75”X 3.35” X 2.75”660LM 5000K
    image description
    		Joint Type: T7” X 3.35” X 2.75” X 2.15” X 2.15”629LM3000K
    image description
    		Joint Type: T7” X 3.35” X 2.75” X 2.15” X 2.15”726LM3500K
    image description
    		White 6ft. Cord, SJTW 18 AWG 5-Conduct (WH/BK/GN/PU/GY)
    image description
    		Joint Type: T7” X 3.35” X 2.75” X 2.15” X 2.15”787LM4000K
    image description
    		Heavy-Duty Auxiliary Hook for up to 1/16" Aircraft Cables with Cable Adjustment
    image description
    		Joint Type: T7” X 3.35” X 2.75” X 2.15” X 2.15”854LM5000K
    image description
    		Joint Type: X3.35” X 2.75” X 2.15” X 2.15”733LM3000K
    image description
    		Joint Type: X3.35” X 2.75” X 2.15” X 2.15”863LM3500K
    image description
    		Joint Type: X3.35” X 2.75” X 2.15” X 2.15”944LM4000K
    image description
    		Joint Type: X3.35” X 2.75” X 2.15” X 2.15”1037LM 5000K
    image description
    		Joint Type: Inside Corner7.25” X 7.25” X 3.35” X 2.75”629LM3000K
    image description
    		Joint Type: Inside Corner7.25” X 7.25” X 3.35” X 2.75”726LM3500K
    image description
    		Joint Type: Inside Corner7.25” X 7.25” X 3.35” X 2.75”787LM4000K
    image description
    		Joint Type: Inside Corner7.25” X 7.25” X 3.35” X 2.75”854LM5000K
    image description
    		Joint Type: 120° Corner6.1” X 6.1” X 3.35” X 2.75”508LM3000K
    image description
    		Joint Type: 120° Corner6.1” X 6.1” X 3.35” X 2.75”575LM3500K
    image description
    		Joint Type: 120° Corner6.1” X 6.1” X 3.35” X 2.75”616LM4000K
    image description
    		Adj. 10ft. 1/16in Double Suspension Cable with Single Keyhole Connector Loop Gripper on Top
    image description
    		Joint Type: 120° Corner6.1” X 6.1” X 3.35” X 2.75”660LM5000K
    image description
    		Adj. 20ft. 1/16in. 1.5mm Double Suspension Cable with Single Keyhole Connector Loop Gripper on Top
    image description
    		Adj. 6ft. 1/16in Suspension Canopy Complete Kit for Both Sides with Keyhole End Connectors
