SCR-24D-MCTP-D
LED Architectural Round Suspended Up/Down Panel Light, 30W/40W/50W, 3000K/3500K/4000K
Technical Specs
- :: Aluminum Housing with Sandy White Finish
- :: LED Superior Architectural Lights
- :: Three 10-feet adjustable suspension cables
- :: Opal Polycarbonate Lens - Direct Down Light
- :: MTCP: Multi Color Temperature & Power (Switches are inside the canopy)
- :: Dimmable: 0~10V Dimming
- :: Lumens: 5116LM
- :: Wattage: 30W/40W/50W
- :: Voltage: 120-277V AC 50/60Hz
- :: Efficacy: 102 LM/W
- :: Beam Angle: 114°H x 114°V
- :: Power Factor: >0.98
- :: Total Harmonic Distortion: <19%
- :: Color Rendering Index: CRI ≥ 80
- :: Color Temp: 3000K/3500K/4000K
- :: Lifespan: 50,000 hours
- :: 5-year warranty
- :: IP Rating: IP20
Applications
- :: Ideal for offices, hotels, corridors, saloons, libraries, meeting rooms, conference halls, and the best solution for modern lighting solutions. It can be used in any indoor application.
Features
ACCESSORIES
| Product Name | Description | |||
|---|---|---|---|---|
 SCR-24D-MCTP-SMB  SPEC MANU | Surface Mounting Bracket |
OPTIONS
