SPEC SHEET

CMC4-ADJ-MCTP-DD-WH

:: Voltage: 120-277V
:: Power Factor: >0.90
:: THD: <20%
:: Wattage:12W/16W/ 20W
:: Efficacy: 80 LPW
:: Aluminum Housing & Glass Lens
:: The lens tilts 90° and rotates 360°
:: Suspension Cable & Canopy Set Accessories Avail.
:: Universal Swivel W/ Rod Kit Accessories Avail. Ambient Operating Temperature: -13ºF to 113ºF
:: Rated life: 70,000 hrs
:: IP Rating: IP40 suitable for damp locations
:: Dimming: (Dual Function) Triac Dimmable at 120V & 0-10V Dimming at 120-277V
:: Total Lumens: 1600LM Max.
:: Color Temperatures: 3000K/4000K/5000K
:: Color Rendering Index: CRI ≥ 80
:: Beam Angle: 40°

:: 4’’ Cylinder, Pendant & Ceiling Cylinder Light, Aluminum Cylinder, White Aluminum Housing, Clear Glass Lens

ACCESSORIES

Product Name	Description
CMC-SRK-218-5C-WH SPEC	Universal Swivel W/ Rod Kit, 18 Or 36 Inches, 5-Wire, White
CMC-SRK-218-5C-BK SPEC	Universal Swivel W/ Rod Kit, 18 Or 36 Inches, 5-Wire, Black
CMC4-TRM-AG SPEC	4-inch ceiling mount cylinder trim, Anodized Gold (AG)
CMC4-TRM-BN SPEC	4-inch ceiling mount cylinder trim, Anodized Gold (AG)
CMC4-HCDK-BK SPEC	4-inch ceiling mount cylinder honeycomb diffuser kit, Black
CMC4-HCDK-BK SPEC	4-inch ceiling mount cylinder honeycomb diffuser kit, Black
CMC4-HCDK-AG SPEC	4-inch ceiling mount cylinder honeycomb diffuser kit, Anodized Gold (AG)
CMC4-HCDK-AG SPEC	4-inch ceiling mount cylinder honeycomb diffuser kit, Anodized Gold (AG)
CMC-CS-8FT-BK SPEC	Suspension Cable & Canopy Set For CMC Series, 8FT, 5-wire, Black
CMC-CS-8FT-WH SPEC	Suspension Cable & Canopy Set for CMC Series, 8FT, 5-Wire, White
CMC-JBCK-BK SPEC	Cylinder And Pendant Lighting J-Box Cover Canopy
CMC-JBCK-WH SPEC	Cylinder And Pendant Lighting J-Box Cover Canopy
CMC4-WPCK-WH SPEC	CMC4 Weatherproof Conversion Kit for Cord or Down-Rod, White
CMC4-WPCK-BK SPEC	CMC4 Weatherproof Conversion Kit for Cord or Down-Rod, Black
CMC4-DL32 SPEC	WMC 4in 32mm Acrylic Drop Lens
CMC4-DS14-WG-KIT SPEC	CMC4 14in Dome Shade, White/Gold

OPTIONS

OPT-EM-CMC46
