SLEA-SERIES

SLEA-SERIES - SINGLE-GANG LED STEP LIGHT ENGINE FOR RECESSED TRIMS

Technical Specs

:: PVC Housing
:: PC Lens
:: Lumens: 86LM
:: Voltage: 12V AC/DC, 120V AC
:: Light Source: Integrated COB LED Bar (Weatherproff) with built-in driver
:: IP Rating: IP67, Wet Locations

image description

Variations
Q & A

Search

Product Name	Material	Material Finish	Light Source	Lens	Accessories Included	Lumens	Color Temp	Dimensions	Watts	Beam Angle	Voltage	Finish	Features
SLEA-12V-27K SPEC IES LUX CAT MANU		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	2700K	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	12V AC/DC
SLEA-12V-30K SPEC IES CAT MANU LUX		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	3000K Warm White, 5000K Cool White	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	12V AC/DC
SLEA-12V-40K SPEC IES LUX CAT MANU		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	4000K	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	12V AC/DC
SLEA-12V-50K SPEC IES LUX CAT MANU		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	3000K Warm White, 5000K Cool White	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	12V AC/DC
SLEA-120V-27K SPEC IES LUX CAT MANU		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	2700K	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	120V AC
SLEA-120V-30K SPEC IES LUX CAT MANU		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	3000K Warm White, 5000K Cool White	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	120V AC
SLEA-120V-40K SPEC IES LUX CAT MANU		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	4000K	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	120V AC
SLEA-120V-50K SPEC IES LUX CAT MANU		PVC Housing	Integrated COB LED Bar (Weatherproof) with built-in driver	PC Lens	1 ft.SPT-2 18AWGLead Wire, PVC Gasket Setfor J-box or weatherproof box mounting	86LM	3000K Warm White, 5000K Cool White	3.3"H x 1.7"D - fits in single gang swith boxes (not included)	2W	-	120V AC
SLT-A-WH SPEC IES LUX CAT MANU	Precision-Cast Aluminum							Face: 5.22"L x 3.30"H \| Opening: 2.40"L x 1.11"H				White Finish
SLT-A-BZ SPEC IES LUX CAT MANU	Precision-Cast Aluminum							Face: 5.22"L x 3.30"H \| Opening: 2.40"L x 1.11"H				Antique Bronze Finish
SLT-A-BN SPEC IES LUX CAT MANU	Precision-Cast Aluminum							Face: 5.22"L x 3.30"H \| Opening: 2.40"L x 1.11"H				Brushed Nickel Finish
SLT-A-ORB SPEC IES LUX CAT MANU	Precision-Cast Aluminum							Face: 5.22"L x 3.30"H \| Opening: 2.40"L x 1.11"H				Oil-Rubbed Bronze Finish
