SFX-G5-SERIES
SFX-G5 - LED Stadium/Building Facade Flood Lights
Technical Specs
- :: Die-cast Aluminum housing with powder coat (Black)
- :: 15KV Surge Protector
- :: Cord Type: 3' SJTW 18/3 AWG Cable
- :: LED: Lumiled Luxeon 5050
- :: Lens: Prismatic Polycarbonate Lens
- :: Lumens: 90,000LM/150,000LM
- :: Wattage: 600W/1000W
- :: Voltage: 120~277 VAC
- :: Efficacy: 150 LM/W
- :: Beam Angle: 30°
- :: Power Factor: 0.90 ~ 0.97
- :: Operating Temp: -40°F to 176°F
- :: Color Rendering Index: >84
- :: Color Tenp: 5000K
- :: Lifespan: 70,000 hours
- :: 7-year warranty
- :: IP Rating: IP65, Wet Locations
Applications
- :: Ideal for stadium lighting, sports fields, parking lots, railways, container yards, architectural lighting, industrial and commercial exterior lighting, tradeshows and exhibitions.
- Variations
- Q & A
| Product Name | Lumens | Color Temp | Watts | Description | Features | ||
|---|---|---|---|---|---|---|---|
SFX-G5-600W-30D-50K  LUX  IES SPEC CAT MANU | 90000LM | 5000K | 600W |      | |||
SFX-G5-1000W-30D-50K SPEC LUX IES CAT MANU | 150000LM | 5000K | 1000W |  | |||
SFX-G5-SH1 CAT SPEC IES LUX MANU | Shroud for 600W | | |||||
SFX-G5-SH2 CAT SPEC LUX MANU IES | Shroud for 1000W | | |||||
SFX-G5-SF CAT SPEC IES LUX MANU | Slip Fitter | | |||||
SFX-G5-RB CAT SPEC LUX IES MANU | Rotatable Base | | |||||
SFX-POINTER CAT SPEC IES LUX MANU | LED Laser Aiming Device | |
ACCESSORIES
| Product Name | Description | |||
|---|---|---|---|---|
 SFX-G5-SH1 CAT SPEC IES LUX MANU | Shroud for 600W | |||
 SFX-G5-SH2 CAT SPEC LUX MANU IES | Shroud for 1000W | |||
 SFX-G5-SF CAT SPEC IES LUX MANU | Slip Fitter | |||
 SFX-G5-RB CAT SPEC LUX IES MANU | Rotatable Base | |||
 SFX-POINTER CAT SPEC IES LUX MANU | LED Laser Aiming Device |
