LWA-SERIES

LWA-LED Cutoff & Adjustable Wall Packs

Technical Specs

:: Full cutoff, dark sky compliant
:: Die-cast aluminum with powder coat finish (Dark Bronze or White)
:: lumileds lexeon 3030 high flux LED
:: TIR optic lens - TYPE II
:: 120~277V
:: CRI: >80
:: Power Factor: 95%
:: Operating Temp:-4°F to 104°F
:: 70,000 hour rated life
:: 7-year warranty
:: Suitable for Wet Locations, IP54

Applications

:: Ideal for general site lighting, alleys, loading docks, doorway, pathway and parking areas.
:: Replace existing HID flood lights/ wall packs
:: Great for use with motion sensors or other instant on/off controls

Variations
Q & A

Product Name	Lumens	Color Temp	Color	Replacement Range	Watts	Dimensions	Factory-Install Options
LWA-12WW SPEC CAT LUX IES MANU	1100LM	3000K	Bronze	50~70 MH	12W	5" (w) x 6"" (H) x 4"" (D)"	OPT-TRS-T20 OPT-SEN-3MRLV-5 OPT-PC-B
LWA-12CW SPEC LUX CAT IES MANU	1200LM	5000K	Bronze	50~70 MH	12W	5" (w) x 6"" (H) x 4"" (D)"	OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-20WW SPEC CAT IES LUX MANU	2000LM	3000K	Bronze	70~100 MH	20W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT
LWA-12NW IES SPEC LUX CAT MANU	1200LM	4000K	Bronze	50~70 MH	12W	5" (w) x 6"" (H) x 4"" (D)"	OPT-EM-OD1EXT
LWA-50WW SPEC CAT LUX IES MANU	4900LM	3000K	Bronze	150~200 MH	50W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-20CW SPEC CAT IES LUX MANU	2200LM	5000K	Bronze	70~100 MH	20W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-20NW IES SPEC CAT MANU	2200LM	4000K	Bronze	70~100 MH	20W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-30CW SPEC CAT LUX IES MANU	3200LM	5000K	Bronze	100~125 MH	30W	8" (w) x 9"" (H) x 4.5"" (D)"
LWA-30NW IES SPEC CAT MANU	3200LM	4000K	Bronze	100~125 MH	30W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-TRS-T20
LWA-30WW SPEC CAT LUX IES MANU	3000LM	3000K	Bronze	100~125 MH	30W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-50CW SPEC CAT LUX IES MANU	5200LM	5000K	Bronze	150~200 MH	50W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-PC-B
LWA-50NW IES SPEC CAT MANU	5200LM	4000K	Bronze	150~200 MH	50W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-80CW SPEC CAT LUX IES MANU	9000LM	5000K	Bronze	200~300 MH	80W	11" (w) x 13"" (H) x 6"" (D)"	OPT-EM-OD2INT OPT-PC-B OPT-SEN-3MRLV-5 OPT-TRS-T20
LWA-80NW IES SPEC LUX CAT MANU	9000LM	4000K	Bronze	200~300 MH	80W	11" (w) x 13"" (H) x 6"" (D)"	OPT-EM-OD2INT OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-80WW SPEC CAT LUX IES MANU	8800LM	3000K	Bronze	200~300 MH	80W	11" (w) x 13"" (H) x 6"" (D)"	OPT-EM-OD2INT OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-120CW SPEC CAT LUX IES MANU	13700LM	5000K	Bronze	300~400 MH	120W	11" (w) x 13"" (H) x 6"" (D)"	OPT-EM-OD2INT OPT-PC-B OPT-SEN-3MRLV-5 OPT-TRS-T20
LWA-120NW SPEC IES CAT MANU	13700LM	4000K	Bronze	300~400 MH	120W	11" (w) x 13"" (H) x 6"" (D)"	OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-120WW SPEC CAT LUX IES MANU	13700LM	3000K	Bronze	300~400 MH	120W	11" (w) x 13"" (H) x 6"" (D)"	OPT-EM-OD2INT OPT-PC-B OPT-SEN-3MRLV-5
LWA-12CW-WH SPEC LUX CAT IES MANU	1200LM	5000K	White	50~70 MH	12W	5" (w) x 6"" (H) x 4"" (D)"	OPT-TRS-T20
LWA-12WW-WH SPEC LUX IES CAT MANU	1100LM	3000K	White	50~70 MH	12W	5" (w) x 6"" (H) x 4"" (D)"	OPT-TRS-T20
LWA-20CW-WH SPEC CAT IES LUX MANU	2200LM	5000K	White	70~100 MH	20W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5
LWA-20WW-WH SPEC CAT IES MANU	2000LM	3000K	White	70~100 MH	20W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-TRS-T20
LWA-30CW-WH SPEC LUX IES CAT MANU	3200LM	5000K	White	100~125 MH	30W	8" (w) x 9"" (H) x 4.5"" (D)"
LWA-30WW-WH SPEC LUX CAT IES MANU	3000LM	3000K	White	100~125 MH	30W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-PC-B OPT-TRS-T20
LWA-50CW-WH SPEC LUX CAT IES MANU	5200LM	5000K	White	150~200 MH	50W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-PC-B OPT-SEN-3MRLV-5 OPT-TRS-T20
LWA-50WW-WH SPEC LUX CAT IES MANU	4900LM	3000K	White	150~200 MH	50W	8" (w) x 9"" (H) x 4.5"" (D)"	OPT-EM-FM1INT OPT-PC-B OPT-TRS-T20 OPT-SEN-3MRLV-5

OPTIONS

OPT-SEN-3MRLV-5
