Results Shown By Individual Products

Product ImageProduct NameTechnical SpecsFeaturesDocuments
SCX4-2FT-20W-MCT4-WSHSCX4-2FT-20W-MCT4-WSH
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power Factor: >0.95
  • :: LPW: 104/106/107/117
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing with Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Mounting Options: Suface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of the Fixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 2314LM/2418LM/2438LM/2511LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT (Selectable with Switch Inside the Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

SPEC

Document Icon

MANU

Document Icon

IES

Document Icon

CAT

SCX-L1FT-20W-MCT4-DSCX-L1FT-20W-MCT4-D
  • :: Voltage: 120~277VAC 50/60Hz
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIconIconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

Document Icon

LUX

Document Icon

MANU

SCX4-1FT-10W-MCT4-DSCX4-1FT-10W-MCT4-D
  • :: Voltage: 120-277V AC 50/60Hz
  • :: Wattage: 10W
  • :: Power Factor: >0.95
  • :: LPW: 110
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of The Fixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 1100LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT(Selectable with Switch Inside the Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

SCX4-3FT-30W-MCT4-WSHSCX4-3FT-30W-MCT4-WSH
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 30W
  • :: Power Factor: >0.95
  • :: LPW: 108/111/113/119
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing with Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of the Fixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 3387LM/3566LM/3604LM/3638LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT (Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

SPEC

Document Icon

MANU

Document Icon

IES

Document Icon

CAT

SCX-2FT-20W-MCT4-DSCX-2FT-20W-MCT4-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power Factor: >0.95
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of TheFixtures
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 2200LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT(Selectable with Switch Inside the Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIcon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-L2FT-40W-MCT4-DSCX-L2FT-40W-MCT4-D
  • :: Voltage: 120~277VAC 50/60Hz
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIconIconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

Document Icon

MANU

SCX-L-MCT4SCX-L-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

Document Icon

MANU

Document Icon

CAT

SCX-3FT-30W-MCT-D-IDLSCX-3FT-30W-MCT-D-IDL
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 30W
  • :: Power Factor: >0.95
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Suspended, Requires Suspension Cables (Not Included) See Page 2
  • :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens:3300LM
  • :: Color Temperatures: 3000K/3500K/4000K
  • :: Multi-CCT(Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: 50,000 Hours Rated Life
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

SPEC

Document Icon

MANU

Document Icon

IES

SCX4-4FT-40W-MCT4-WSHSCX4-4FT-40W-MCT4-WSH
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 40W
  • :: Power Factor: >0.95
  • :: LPW: 110/112/115/122
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing with Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of the Fixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 4648LM/4810LM/4954LM/4970LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT (Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-3FT-30W-MCT4-DSCX-3FT-30W-MCT4-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 30W
  • :: Power Factor: >0.95
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of The Fixtures
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 3300LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT(Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIcon
Document Icon

SPEC

Document Icon

MANU

Document Icon

IES

Document Icon

CAT

SCX-T-MCT4SCX-T-MCT4
  • :: Lumens: 629LMm/726LM/787LM/854LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

LUX

Document Icon

SPEC

Document Icon

IES

Document Icon

MANU

Document Icon

CAT

SCX-4FT-40W-MCT4-DSCX-4FT-40W-MCT4-D
  • :: Voltage: 120~277VAC 50/60Hz
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIconIcon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX4-4FT-40W-MCT-D-IDLSCX4-4FT-40W-MCT-D-IDL
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 40W
  • :: Power Factor: >0.95
  • :: LPW: 110/112/115/122
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing with Matte White Finish
  • :: Custom Colors Available
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of the Fixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 4954LM
  • :: Color Temperatures: 3000K/3500K/4000K
  • :: Multi-CCT (Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

SPEC

Document Icon

MANU

Document Icon

IES

Document Icon

CAT

SCX-T-MCT4SCX-T-MCT4
  • :: Lumens: 629LM/726LM/787LM/854LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

Document Icon

CAT

Document Icon

MANU

Document Icon

IES

SCX-6FT-60W-MCT4-DSCX-6FT-60W-MCT4-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 60W
  • :: Power Factor: >0.95
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of The Fixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 66500LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT(Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIcon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX4-6FT-60W-MCT4-DSCX4-6FT-60W-MCT4-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 60W
  • :: Power Factor: >0.95
  • :: LPW: 113/ 121/ 118/ 120
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of TheFixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 6774LM/ 7275LM/ 7132LM/ 7208LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT(Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

SCX-IC-MCT4SCX-IC-MCT4
  • :: Lumens: 629LM/726LM/787LM/854LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

LUX

Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-8FT-80W-MCT4-DSCX-8FT-80W-MCT4-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor: >0.95
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: LPW: 110
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of The Fixtures
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 8800LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT(Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIcon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX4-8FT-80W-MCT-D-IDLSCX4-8FT-80W-MCT-D-IDL
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor:>0.95
  • :: LPW: 116/120/124
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing with Matte White Finish
  • :: Custom Colors Available
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of the Fixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 9291LM/9295LM/9909LM/9621LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT (Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
IconIconIconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

MANU

Document Icon

CAT

SCX-IC-MCT4SCX-IC-MCT4
  • :: Lumens: 629LM/726LM/787LM/854LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

Document Icon

CAT

Document Icon

IES

Document Icon

MANU

SCX4-8FT-80W-MCT4-DSCX4-8FT-80W-MCT4-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor: >0.95
  • :: LPW: 116/ 124/ 120/ 124
  • :: Total Harmonic Distortion: ≤ 20 %
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Adjustable Suspension Brackets Provided on Top of TheFixtures
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 9295M/ 9940LM/ 9621LM/ 9909LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: Multi-CCT(Selectable Switch Inside Fixture)
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: 50,000 Hours Rated Life
  • :: 5-Year Warranty
IconIconIconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

SCX-2FT-20W-30K-DSCX-2FT-20W-30K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 2200LM
  • :: Color Temperatures: 3000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX4-L-MCT4SCX4-L-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

SCX-2FT-20W-35K-DSCX-2FT-20W-35K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 2200LM
  • :: Color Temperatures: 3500K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX4-T-MCT4SCX4-T-MCT4
  • :: Lumens: 629LM/726LM/787LM/854LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

SCX-Y-MCT4SCX-Y-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

MANU

Document Icon

IES

Document Icon

LUX

Document Icon

SPEC

Document Icon

CAT

SCX-2FT-20W-40K-DSCX-2FT-20W-40K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 2200LM
  • :: Color Temperatures: 4000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX4-X-30KSCX4-X-30K
  • :: Lumens: 733LM/863LM/944LM/1037LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

SCX-Y-6IN-MCT4SCX-Y-6IN-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

MANU

Document Icon

IES

Document Icon

LUX

Document Icon

SPEC

Document Icon

CAT

SCX-2FT-20W-50K-DSCX-2FT-20W-50K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 2200LM
  • :: Color Temperatures: 5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-Y-9IN-MCT4SCX-Y-9IN-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

IES

Document Icon

LUX

Document Icon

MANU

Document Icon

SPEC

Document Icon

CAT

SCX4-IC-MCT4SCX4-IC-MCT4
  • :: Lumens: 629LM/726LM/787LM/854LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
Document Icon

SPEC

Document Icon

IES

Document Icon

LUX

SCX-3FT-30W-30K-DSCX-3FT-30W-30K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 30W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 3300LM
  • :: Color Temperature: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-9IN-MCT4SCX-9IN-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperature: 3000K/3500K/4000K/5000K
  • :: Ambient Temperature: -13°F~104°F
  • :: Dimmable: 0~10V dimmable
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

Document Icon

MANU

Document Icon

IES

Document Icon

CAT

SCX-3FT-30W-35K-DSCX-3FT-30W-35K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 30W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 3300LM
  • :: Color Temperature: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-3FT-30W-40K-DSCX-3FT-30W-40K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 30W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 3300LM
  • :: Color Temperature: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-3FT-30W-50K-DSCX-3FT-30W-50K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 30W
  • :: Power Factor: >0.95
  • :: LPW: 110
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 3300LM
  • :: Color Temperature: 5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-4FT-40W-30K-DSCX-4FT-40W-30K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 40W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 4400LM
  • :: Color Temperatures: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-4FT-40W-35K-DSCX-4FT-40W-35K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 40W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 4400LM
  • :: Color Temperatures: 3500K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-4FT-40W-40K-DSCX-4FT-40W-40K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 40W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 4400LM
  • :: Color Temperatures: 4000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-4FT-40W-50K-DSCX-4FT-40W-50K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 40W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 4400LM
  • :: Color Temperatures: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-6FT-60W-30K-DSCX-6FT-60W-30K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 60W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 6600LM
  • :: Color Temperatures: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-6FT-60W-35K-DSCX-6FT-60W-35K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 60W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 6600LM
  • :: Color Temperatures: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-6FT-60W-40K-DSCX-6FT-60W-40K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 60W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 6600LM
  • :: Color Temperatures: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-6FT-60W-50K-DSCX-6FT-60W-50K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 60W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 6600LM
  • :: Color Temperatures: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

IES

Document Icon

CAT

SCX-8FT-80W-30K-DSCX-8FT-80W-30K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 8800LM
  • :: Color Temperatures: 3000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

CAT

SCX-8FT-80W-35K-DSCX-8FT-80W-35K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 8800LM
  • :: Color Temperatures: 3500K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

CAT

SCX-8FT-80W-40K-DSCX-8FT-80W-40K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 8800LM
  • :: Color Temperatures: 3000K/3500K/4000K /5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

CAT

SCX-8FT-80W-50K-DSCX-8FT-80W-50K-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 80W
  • :: Power Factor: >0.95
  • :: Efficacy: 110 LPW
  • :: Low Profile Modern Design
  • :: Aluminum Housing With Matte White Finish
  • :: Custom Colors Available
  • :: Lens Snaps into Housing
  • :: Make Different Connections Via T/L/X Joints on Both Ends
  • :: Mounting Options: Surface, Suspended, Wall, Recessed
  • :: IP Rating: IP54
  • :: Operating Temperature: -13°F~104°F
  • :: 5-Year Warranty
  • :: Dimmable: 0~10V Dimming
  • :: Total Lumens: 8800LM
  • :: Color Temperatures: 5000K
  • :: Color Rendering Index: CRI ≥ 80
  • :: Up Light Option Available
  • :: Beam Angle: 104.8°(H) x 100.5°(V)
  • :: 50,000 Hours Rated Life
Icon
Document Icon

MANU

Document Icon

SPEC

Document Icon

CAT

SCX-L-MCT4SCX-L-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

SCX-T-MCT4SCX-T-MCT4
  • :: Lumens: 629LM/726LM/787LM/854LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

SCX-C120-MCT4SCX-C120-MCT4
  • :: Lumens: 508LM/575LM/616LM/660LM
  • :: Color Temperatures: 3000K/3500K/4000K/5000K
  • :: CRI:>80
  • :: Power Factor:>0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

SCX-T-50KSCX-T-50K
  • :: Lumens: 854LM
  • :: Color Temperatures: 5000K
  • :: CRI: >80
  • :: Power Factor: >0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

SCX-X-40KSCX-X-40K
  • :: Lumens: 944LM
  • :: Color Temperatures: 4000K
  • :: CRI: >80
  • :: Power Factor: >0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

SCX-X-50K SCX-X-50K
  • :: Lumens: 1037LM
  • :: Color Temperatures: 5000K
  • :: CRI: >80
  • :: Power Factor: >0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

SCX-C120-30KSCX-C120-30K
  • :: Lumens: 508LM
  • :: Color Temperatures: 3000K
  • :: CRI: >80
  • :: Power Factor: >0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

SCX-C120-50KSCX-C120-50K
  • :: Lumens: 660LM
  • :: Color Temperatures: 5000K
  • :: CRI: >80
  • :: Power Factor: >0.95
  • :: Efficacy: 110LM/W
  • :: IP Rating: IP54
  • :: Life Span: 50,000 hours
  • :: Housing: White, Aluminum
  • :: Lens: Frosted Polycarbonate
IconIcon
Document Icon

SPEC

CRLC4-15W-40K-SA-DCRLC4-15W-40K-SA-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 15W
  • :: Power factor: >0.90
  • :: Efficacy: 85 LPW
  • :: 4” Haze & White Finish TRIM
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to operate in temperatures 113°F
  • :: IC-Rated
  • :: Suitable for Damp Locations
  • :: 5-Year Warranty
  • :: MCT: The switch is on the light engine
  • :: Dimming: 0~10V Dimmable
  • :: Total lumens: 1275LM
  • :: Color temperature: 3000K/4000K/5000K
  • :: Color rendering index: >80
  • :: Lifespan: 50,000 hrs.
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-15W-50K-SA-DCRLC4-15W-50K-SA-D
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-15W-MCT-SA-DCRLC4-15W-MCT-SA-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 15W
  • :: Power factor: >0.90
  • :: Efficacy: 85 LPW
  • :: 4” Haze & White Finish TRIM
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to operate in temperatures 113°F
  • :: IC-Rated
  • :: Suitable for Damp Locations
  • :: 5-Year Warranty
  • :: MCT: The switch is on the light engine
  • :: Dimming: 0~10V Dimmable
  • :: Total lumens: 1275LM
  • :: Color temperature: 3000K/4000K/5000K
  • :: Color rendering index: >80
  • :: Lifespan: 50,000 hrs.
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-15W-MCT-SA-D-WHCRLC4-15W-MCT-SA-D-WH
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 15W
  • :: Power factor: >0.90
  • :: Efficacy: 85 LPW
  • :: 4” Haze & White Finish TRIM
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to operate in temperatures 113°F
  • :: IC-Rated
  • :: Suitable for Damp Locations
  • :: 5-Year Warranty
  • :: MCT: The switch is on the light engine
  • :: Dimming: 0~10V Dimmable
  • :: Total lumens: 1275LM
  • :: Color temperature: 3000K/4000K/5000K
  • :: Color rendering index: >80
  • :: Lifespan: 50,000 hrs.
IconIconIconIconIconIcon
Document Icon

SPEC

CRLC4-15W-50K-SA-D-WHCRLC4-15W-50K-SA-D-WH
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 15W
  • :: Power factor: >0.90
  • :: Efficacy: 85 LPW
  • :: 4” Haze & White Finish TRIM
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to operate in temperatures 113°F
  • :: IC-Rated
  • :: Suitable for Damp Locations
  • :: 5-Year Warranty
  • :: MCT: The switch is on the light engine
  • :: Dimming: 0~10V Dimmable
  • :: Total lumens: 1275LM
  • :: Color temperature: 3000K/4000K/5000K
  • :: Color rendering index: >80
  • :: Lifespan: 50,000 hrs.
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-15W-40K-SA-D-WHCRLC4-15W-40K-SA-D-WH
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 15W
  • :: Power factor: >0.90
  • :: Efficacy: 80~85LM/W
  • :: 4” Haze or White Finish Square wall wash trim
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to operate in temperatures 113°F
  • :: No IC-Rated
  • :: Lifespan: 50,000 hrs.
  • :: Suitable for Damp Locations
  • :: Dimming: 0~10V Dimmable
  • :: Recommended Dimmers: DVTV(LUTRON),IP710(LEVITON)
  • :: Total lumens: 1200~1275LM
  • :: Color temperature: 5000K/4000K/3000K & MCT: 3000K/4000K/5000K
  • :: Color rendering index: >80
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-15W-30K-SA-D-WHCRLC4-15W-30K-SA-D-WH
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-30K-SA-DCRLC4-20W-30K-SA-D
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-40K-SA-DCRLC4-20W-40K-SA-D
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-50K-SA-DCRLC4-20W-50K-SA-D
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-MCT-SA-DCRLC4-20W-MCT-SA-D
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power factor: >0.90
  • :: Efficacy: 85 LPW
  • :: 4” Haze & White Finish TRIM
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to operate in temperatures 113°F
  • :: IC-Rated
  • :: Suitable for Damp Locations
  • :: 5-Year Warranty
  • :: MCT: The switch is on the light engine
  • :: Dimming: 0~10V Dimmable
  • :: Total lumens: 1720LM
  • :: Color temperature: 3000K/4000K/5000K
  • :: Color rendering index: >80
  • :: Lifespan: 50,000 hrs.
IconIconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-30K-SA-D-WHCRLC4-20W-30K-SA-D-WH
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-40K-SA-D-WHCRLC4-20W-40K-SA-D-WH
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-50K-SA-D-WHCRLC4-20W-50K-SA-D-WH
  • :: Rated Power: 15W & 20W
  • :: CRI: Ra>80
  • :: THD: <20%
  • :: Power Factor: >0.9
  • :: Life Span: 50,000 hours
  • :: Mounting: Recessed
  • :: Driver Efficiency: >87%
  • :: Temperature Rating: Designed to operate in temperatures 113°F
IconIconIconIconIcon
Document Icon

SPEC

CRLC4-20W-MCT-SA-D-WHCRLC4-20W-MCT-SA-D-WH
  • :: Voltage: 120-277VAC 50/60Hz
  • :: Wattage: 20W
  • :: Power factor: >0.90
  • :: Efficacy: 85 LPW
  • :: 4” Haze & White Finish TRIM
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to operate in temperatures 113°F
  • :: IC-Rated
  • :: Suitable for Damp Locations
  • :: 5-Year Warranty
  • :: MCT: The switch is on the light engine
  • :: Dimming: 0~10V Dimmable
  • :: Total lumens: 1720LM
  • :: Color temperature: 3000K/4000K/5000K
  • :: Color rendering index: >80
  • :: Lifespan: 50,000 hrs.
IconIconIconIconIcon
Document Icon

SPEC

CRLC6-15W-50K-SA-D-WHCRLC6-15W-50K-SA-D-WH
  • :: Voltage: 120-277VAC50/60Hz
  • :: Wattage: 15W
  • :: Power Factor: >0.90
  • :: Efficacy: 85 LPW
  • :: 6” Haze & White Finish TRIM
  • :: Mounting Options: Recessed
  • :: Temperature Rating: Designed to Operate In Temperatures 113°F
  • :: Housing Not Required. Two Spring Clips To HoldThe Fixture In Place
  • :: IC-Rated
  • :: Suitable for Damp Locations
  • :: 5-Year Warranty
  • :: MCT: The Switch is On The Light Engine
  • :: Dimming: 0~10V Dimmable
  • :: Total Lumens: 1275LM
  • :: Color Temperature: 5000K
  • :: Color Rendering index: >80
  • :: Lifespan: 50,000 hrs.
IconIconIconIconIcon
Document Icon

SPEC
